Electrodepot 40 Amp 4 Pole 2NO 2NC IEC 400V Contactor (Silent Operation) – 110-120VAC Coil, Inductive 40A, Resistive 60A with Mounting Base for DIN Rail

Up To 50% OFF Electrodepot 40 Amp 4 Pole 2NO 2NC IEC 400V Contactor (Silent Operation) – 110-120VAC Coil, Inductive 40A, Resistive 60A with Mounting Base for DIN Rail Reviews

So you can check out the other reviews at Amazon.com

only with $ 128.99

INDUSTRIAL QUALITY COMPONENTS – 40Amp General Purpose Contactor for home and industrial uses, compatible with 35mm DIN rails, with power status indicator. Complies with IEC/EN standards for consistent and reliable installation. Additionally, 2 Normally Open (NO) and 2 Normally Closed (NC) poles for transfer switch applications

APPLICATIONS – Lighting, motor or switching. AC-1 for resistance furnaces, incandescent lamps or electric heaters; and AC-3 for air conditioners, compressors or fans. 24/120/220/277 V, with an energy saving, silent and no humming coil

FULL AMP LOAD – Works for 40 Amp, 50 Amp, 60 Amp and 63 Amp loads. Inductive/Motor Load: 40Amp. Resistive/Incandescent Load: 63Amp. DC Load: 30Amp @ 24VDC. Power Lug Terminal Capacity AWG # 4

COIL VOLTAGE AND LOAD – Voltage: AC 110V/120V, 50/60Hz. Load: 52 VA Inrush and 10VA Sealed

DIMENSIONS (approx.) – 54 x 85 x 67 mm / 2.2'' x 3.3'' x 2.5'' (Width x Height x Depth)

› See more product details

Product Description

40 Amp 4 Pole, 2 Normally Open and 2 Normally Closed, IEC 400V Contactor for home or industrial uses. Perfectly compatible with DIN rail mounting.
Works for 40 Amp, 50 Amp, 60 Amp and 63 Amp loads. It features a convenient power status indicator, and an energy saving, silent and no humming coil.
With applications in lighting, motor and switching

Technical Specifications:
– Contactor IEC 400V
– Contactor Type 2NO 2NC
– Full Load Amps-Inductive 40
– Full Load Amps-Resistive 63
– DC Load: 30A, @ 24VDC
– Power status indicator
– Number of Poles 4
– Coil Volts: 110/120VAC, 50/60 Hz
– Coil Load: Inrush 52VA, Sealed 10VA
– IEC AC Rate: AC-1, 10 kW. AC-3, 8 kW
– Electric e strength: 4 kV
– Operating Temperature: -30…+70 °C (-22…+158 °F)
– 1 HP @ 1 Phase - 120V
– 2 HP @ 1 Phase - 230V
– 5 HP @ 3 Phase - 208V
– 5 HP @ 3 Phase - 230V
– 10HP @ 3 Phase - 480V
– Weight: 0.88 lb (0.42 kg)
– CE approved 61095, UL pending
– Base or DIN 35mm mount

Wiring:
Solid Conductor: 25 mm2 Max torque 0.6 Nm
Stranding Conductor: 16 mm2, Max torque 0.6 Nm

Compliance:
EN 60947-4-1, EN 60947-5-1, IEC 947-2, IEC 60947-4-1, IEC 60947-5-1, VDE 0660
